对比研究快慢速扩弓治疗对鼻腔及上颌骨结构的影响

doi:10.7518/hxkq.2019.05.015

华西口腔医学杂志 ›› 2019, Vol. 37 ›› Issue (5): 533-536.doi: 10.7518/hxkq.2019.05.015

对比研究快慢速扩弓治疗对鼻腔及上颌骨结构的影响

刘俊玲¹(),李洪发²,闫卉¹

1.天津市南开医院
2.天津医科大学口腔医院,天津 300000

收稿日期:2019-07-01 修回日期:2019-08-13 出版日期:2019-10-01 发布日期:2019-10-15
通讯作者: 刘俊玲 E-mail:493757935@qq.com
作者简介:刘俊玲,主治医师,硕士,E-mail：493757935@qq.com

Comparing the effects of fast and slow expansion on nasal cavity and maxilla structure

Liu Junling¹(),Li Hongfa²,Yan Hui¹

1. Tianjin Nankai Hospital, Tianjin 300000, China
2.Stomatological Hospital, Tianjin Medical University, Tianjin 300000, China

Received:2019-07-01 Revised:2019-08-13 Online:2019-10-01 Published:2019-10-15
Contact: Junling Liu E-mail:493757935@qq.com

摘要/Abstract

摘要：

目的比较快慢速扩弓治疗对鼻腔结构改建的影响。方法选取牙弓狭窄者40例,随机分为2组,术前和术后分别拍摄锥形束CT,比较治疗前后鼻腔结构的变化。结果快速扩弓组较慢速扩弓组基骨弓宽度和鼻腔骨性结构打开量大;上颌骨宽度和鼻腔软组织变化无明显差异。结论快速扩弓治疗更有益于改善鼻腔功能。

关键词: 快速扩弓, 慢速扩弓, 鼻腔, 锥形束CT, 鼻通气量

Abstract:

Objective This study aims to compare the effects of fast and slow expansion on nasal cavity structure. Methods A total of 40 patients were selected and randomly divided into two groups. Cone-beam computer tomography (CBCT) was obtained before and after surgery and used for comparing the changes in nasal structure before and after treatment. Results Fast expansion had resulted in greater changes in the basilar and nasal bone arch extension structures than slow expansion. No significant difference at maxillary width and nasal parenchyma. Conclusion Rapid expansion therapy has more beneficial effects on nasal function.

Key words: fast expansion, slow expansion, nasal cavity, cone-beam computer tomography, nasal ventilation

中图分类号:

R783.5

刘俊玲,李洪发,闫卉. 对比研究快慢速扩弓治疗对鼻腔及上颌骨结构的影响[J]. 华西口腔医学杂志, 2019, 37(5): 533-536.

Liu Junling,Li Hongfa,Yan Hui. Comparing the effects of fast and slow expansion on nasal cavity and maxilla structure[J]. West China Journal of Stomatology, 2019, 37(5): 533-536.

图/表 8

图 1

图 2

图 3

图 4

图 5

表1

表 2

表 3

参考文献 17

[1]	McNamara JA Jr, Lione R, Franchi L , et al. The role of rapid maxillary expansion in the promotion of oral and general health[J]. Prog Orthod, 2015,16:33.
[2]	罗春花, 郑之峻, 徐卫华 , 等. 锥形束CT评价上颌快速扩弓后鼻上颌复合体及上气道的三维形态改变[J]. 中国组织工程研究, 2017,21(36):5781-5786.
	Luo CH, Zheng ZJ, Xu WH , et al. Three-dimensional reconstruction of the nasomaxillary complex and upper airway following rapid maxillary expansion by cone-beam CT[J]. Chin J Tissue Eng Res, 2017,21(36):5781-5786.
[3]	陈扬熙 . 口腔正畸学[M]. 北京: 人民卫生出版社, 2012.
	Chen YX. Orthodontics[M]. Beijing: People’s Medical Publishing House, 2012.
[4]	刘俊玲 . 生长发育高峰期患者快慢速扩弓的CBCT研究[D]. 天津: 天津医科大学, 2013.
	Liu JL . Comparison of rapid and slow maxillary expansion in the growth period by CBCT[D]. Tianjin: Tianjin Medical University, 2013.
[5]	李心慧, 雷雪, 许诺 , 等. 上颌横向发育不足治疗方法的研究进展[J]. 现代口腔医学杂志, 2017,31(3):150-153.
	Li XH, Lei X, Xu N , et al. Advances in the treatment of maxillary lateral dysplasia[J]. J Modern Stomatol, 2017,31(3):150-153.
[6]	Lo Giudice A, Fastuca R, Portelli M , et al. Effects of rapid vs slow maxillary expansion on nasal cavity dimensions in growing subjects: a methodological and reproducibility study[J]. Eur J Paediatr Dent, 2017,18(4):299-304.
[7]	Martina R, Cioffi I, Farella M , et al. Transverse changes determined by rapid and slow maxillary expansion—a low-dose CT-based randomized controlled trial[J]. Orthod Craniofac Res, 2012,15(3):159-168.
[8]	Park JH, Bayome M, Zahrowski JJ , et al. Displacement and stress distribution by different bone-borne palatal expanders with facemask: a 3-dimensional finite element analysis[J]. Am J Orthod Dentofac Orthop, 2017,151(1):105-117.
[9]	Garrett BJ, Caruso JM, Rungcharassaeng K , et al. Skeletal effects to the maxilla after rapid maxillary expansion assessed with cone-beam computed tomography[J]. Am J Orthod Dentofac Orthop, 2008, 134(1):8.e1-8.e11.
[10]	Habeeb M, Boucher N, Chung CH . Effects of rapid palatal expansion on the sagittal and vertical dimensions of the maxilla: a study on cephalograms derived from cone-beam computed tomography[J]. Am J Orthod Dentofacial Orthop, 2013,144(3):398-403.
[11]	Habersack K, Karoglan A, Sommer B , et al. High-resolution multislice computerized tomography with multiplanar and 3-dimensional reformation imaging in rapid palatal expansion[J]. Am J Orthod Dentofacial Orthop, 2007,131(6):776-781.
[12]	Yu HS, Baik HS, Sung SJ , et al. Three-dimensional finite-element analysis of maxillary protraction with and without rapid palatal expansion[J]. Eur J Orthod, 2007,29(2):118-125.
[13]	Akkaya S, Lorenzon S, Uçem TT . A comparison of sagittal and vertical effects between bonded rapid and slow maxillary expansion procedures[J]. Eur J Orthod, 1999,21(2):175-180.
[14]	Pangrazio-Kulbersh V, Wine P, Haughey M , et al. Cone beam computed tomography evaluation of changes in the naso-maxillary complex associated with two types of maxillary expanders[J]. Angle Orthod, 2012,82(3):448-457.
[15]	Palaisa J, Ngan P, Martin C , et al. Use of conventional tomography to evaluate changes in the nasal cavity with rapid palatal expansion[J]. Am J Orthod Dentofacial Orthop, 2007,132(2):458-466.
[16]	Wertz R, Dreskin M . Midpalatal suture opening: a normative study[J]. Am J Orthod, 1977,71(4):367-381.
[17]	de Almeida AM, Ozawa TO, Alves ACM , et al. Slow versus rapid maxillary expansion in bilateral cleft lip and palate: a CBCT randomized clinical trial[J]. Clin Oral Investig, 2017,21(5):1789-1799.

上颌骨宽度	快速组/%	慢速组/%	t值	P值
上颌复合体颧突（M1)	18.7±1.5	18.3±1.7	0.7	>0.05
上颌复合体中部（M2)	22.4±2.9	21.7士3.5	0.6	>0.05
上颌复合体颧牙槽嵴（M3 )	27.8士3.1	23.8±2.4	3.9	<0.05

上颌基骨弓宽度	快速组/%	慢速组/%	t值	P值
尖牙基骨（A3)	32.0±2.4	26.4±3.7	4.8	<0.05
第一前磨牙基骨（A4)	28.2士4.6	24.2±2.5	3.0	<0.05
第二前磨牙基骨（A5)	26.3±1.8	23.1±2.8	3.7	<0.05
第一磨牙基骨（A6)	25.8±2.3	22.7士1.5	4.5	<0.05

鼻腔宽度	快速组/%	慢速组/%	t值	P值
前鼻腔侧壁	9.4±1.8	4.9士2.8	5.3	<0.05
前鼻腔基底	21.1±2.3	19.4士1.9	2.2	<0.05
后鼻腔侧壁	24.6士3.5	16.9士2.4	7	<0.05
后鼻腔基底	21.5±2.6	18.3士4.9	2.3	<0.05
鼻腔软组织侧壁	3.5士1.9	4.2士2.2	0.9	>0.05
鼻腔软组织基底	7.5士2.6	5.3士1.2	2.9	<0.05
