阻生下颌第二磨牙下颌骨的三维分析

doi:10.7518/hxkq.2020.03.008

华西口腔医学杂志 ›› 2020, Vol. 38 ›› Issue (3): 274-279.doi: 10.7518/hxkq.2020.03.008

阻生下颌第二磨牙下颌骨的三维分析

范炜¹^,², 高德国²^,³, 王宇婷¹^,², 厉丹丹¹^,², 王震东¹^,²()

1.南京医科大学口腔疾病研究江苏省重点实验室,南京 210000
2.南京医科大学附属口腔医院正畸科,南京 210000
3.镇江市口腔医院正畸科,镇江 212000

收稿日期:2019-08-12 修回日期:2020-02-18 出版日期:2020-06-01 发布日期:2020-05-28
通讯作者: 王震东 E-mail:wangzhd74@hotmail.com
作者简介:范炜,住院医师,硕士,E-mail: 1191628831@qq.com
基金资助:
江苏省口腔疾病研究重点实验室开放课题基金(JSKLOD-KF-1710);江苏高校优势学科建设工程资助项目(2018-87);江苏省“科教强卫工程”医学重点学科建设项目(zdxka2016026)

Three-dimensional analysis of the mandible with impacted mandibular second molar

Fan Wei¹^,², Gao Deguo²^,³, Wang Yuting¹^,², Li Dandan¹^,², Wang Zhendong¹^,²()

1.Jiangsu Key Laboratory of Oral Diseases, Nanjing Medical University, Nanjing 210000, China
2.Dept. of Orthodontics, Affiliated Hospital of Stomatological, Nanjing Medical University, Nanjing 210000, China
3.Dept. of Orthodontics, Zhenjiang Stomatological Hospital, Zhenjiang 212000, China

Received:2019-08-12 Revised:2020-02-18 Online:2020-06-01 Published:2020-05-28
Contact: Zhendong Wang E-mail:wangzhd74@hotmail.com
Supported by:
Opening of the Jiangsu Key Laboratory of Oral Diseases, Nanjing Medical University(JSKLOD-KF-1710);Priority Academic Program Development of Jiangsu Higher Education Institutions(2018-87);Jiangsu Provincial Key Medical Discipline(zdxka2016026)

摘要/Abstract

摘要：

目的研究阻生下颌第二磨牙患者下颌骨的发育和形态特征,并且通过三维测量和分析预测下颌发育的可能趋势。方法筛选出阻生组和对照组各88例,利用Mimics软件建模进行三维测量,共确定了23个标记点和17个测量值,对测量值进行t检验分析。结果阻生组中下颌体长度、第一磨牙后萌出间隙、下颌角间距和第一磨牙间宽的值低于对照组（P<0.05）,颌下角的值高于对照组（P<0.05）。结论本研究发现下颌第二磨牙阻生患者的下颌骨呈现出在矢状向和宽度上的发育不足,下颌第二磨牙阻生是其退化的表现之一。

关键词: 三维测量, 下颌第二磨牙阻生, 下颌骨, 退化

Abstract:

Objective To study the developmental and morphological characteristics of the mandible in patients with impacted mandibular second molar and to predict the possible trend of mandibular development via three-dimensional (3D) measurement and analysis. Methods A total of 88 cases of impacted group and 88 cases of control group were screened out. 3D measurements were performed by using Mimics software. A total of 23 landmark points and 17 measurements were determined. The measurements were analyzed by t-test. Results The mandible length, the space between the first molars, the space between mandibular angles, and the width between the first molars in the impacted group were lower than those in the control group (P<0.05). Moreover, the value of the submandibular angle was higher than that in the control group (P<0.05). Conclusion The impacted mandible of patients with mandibular second molar showed lack of sagittal and width development, and the impacted mandibular second molar was a manifestation of its degeneration.

Key words: three-dimensional measurement, impacted mandibular second molar, mandible, degeneration

中图分类号:

R782.1

范炜, 高德国, 王宇婷, 厉丹丹, 王震东. 阻生下颌第二磨牙下颌骨的三维分析[J]. 华西口腔医学杂志, 2020, 38(3): 274-279.

Fan Wei, Gao Deguo, Wang Yuting, Li Dandan, Wang Zhendong. Three-dimensional analysis of the mandible with impacted mandibular second molar[J]. West China Journal of Stomatology, 2020, 38(3): 274-279.

图/表 6

表 1

表 2

图 1

图 2

表 3

图 3

参考文献 19

[1]	Kaczor-Urbanowicz K, Zadurska M, Czochrowska E . Impacted teeth: an interdisciplinary perspective[J]. Adv Clin Exp Med, 2016,25(3):575-585. doi: 10.17219/acem/37451 URL
[2]	Juodzbalys G, Daugela P . Mandibular third molar impaction: review of literature and a proposal of a classification[J]. J Oral Maxillofac Res, 2013,4(2):e1.
[3]	胡圣望, 熊炎斌, 肖菊芳 , 等. 成人下颌骨第三磨牙阻生关系的研究[J]. 咸宁医学院学报, 2001,15(3):153-156.
	Hu SW, Xiong YB, Xiao JF , et al. A study of the relationship between the mandible and the impacted mandibular third molar[J]. J Xianning Med Coll, 2001,15(3):153-156.
[4]	Cho SY, Ki Y, Chu V , et al. Impaction of permanent mandibular second molars in ethnic Chinese schoolchildren[J]. J Can Dent Assoc, 2008,74(6):521.
[5]	Evans R . Incidence of lower second permanent molar impaction[J]. Br J Orthod, 1988,15(3):199-203.
[6]	Ferro F, Funiciello G, Perillo L , et al. Mandibular lip bumper treatment and second molar eruption disturbances[J]. Am J Orthod Dentofacial Orthop, 2011,139(5):622-627. doi: 10.1016/j.ajodo.2009.07.024 URL
[7]	Kritzler K . CBCT imaging vs conventional radiography[J]. Am J Orthod Dentofac Orthop, 2017,152(2):146-148. doi: 10.1016/j.ajodo.2017.04.018 URL
[8]	Tsolakis AI, Kalavritinos M, Bitsanis E , et al. Reliability of different radiographic methods for the localization of displaced maxillary canines[J]. Am J Orthod Dentofacial Orthop, 2018,153(2):308-314. doi: 10.1016/j.ajodo.2017.06.026 URL
[9]	Thiesen G, Freitas MPM, Araújo EA , et al. Three-dimensional evaluation of craniofacial characteristics related to mandibular asymmetries in skeletal Class Ⅰ patients[J]. Am J Orthod Dentofacial Orthop, 2018,154(1):91-98.
[10]	沈晓玲, 刘敏, 黄海霞 , 等. 三维数字化解剖测量颞下颌关节的骨性结构[J]. 中国组织工程研究, 2016,20(20):2893-2898.
	Shen XL, Liu M, Huang HX , et al. Three-dimensional digital model measurements of the temporomandibular joint[J]. Chin J Tis Eng Res, 2016,20(20):2893-2898.
[11]	Kelly MP, Vorperian HK, Wang Y , et al. Characterizing mandibular growth using three-dimensional imaging techniques and anatomic landmarks[J]. Arch Oral Biol, 2017,77:27-38.
[12]	Cassetta M, Altieri F, Di Mambro A , et al. Impaction of permanent mandibular second molar: a retrospective study[J]. Med Oral Patol Oral Cir Bucal, 2013,18(4):e564-e568.
[13]	Capelli J Jr . Mandibular growth and third molar impaction in extraction cases[J]. Angle Orthod, 1991,61(3):223-229.
[14]	Balraj L, Nagaraj T, Irugu K , et al. Radiographic assessment of distribution of mandibular third molar impaction: a retrospective study[J]. J Indian Acad Oral Med Radiol, 2016,28(2):145. doi: 10.4103/0972-1363.195125 URL
[15]	Fu PS, Wang JC, Wu YM , et al. Impacted mandibular second molars[J]. Angle Orthod, 2012,82(4):670-675. doi: 10.2319/102111-656.1 URL
[16]	Je E . Gender variation in pattern of mandibular third molar impaction[J]. J Dent Oral Disord Ther, 2017,5(2):1-4.
[17]	Neychev D, Chenchev I, Atanasov D . Mandibular second molar impaction—literature review and case reports[J]. Scr Sci Med Dent, 2017,3(1):70.
[18]	Sawchuk D, Currie K, Vich ML , et al. Diagnostic methods for assessing maxillary skeletal and dental transverse deficiencies: a systematic review[J]. Korean J Orthod, 2016,46(5):331-342.
[19]	Shapira Y, Finkelstein T, Shpack N , et al. Mandibular second molar impaction. PartⅠ: genetic traits and characteristics[J]. Am J Orthod Dentofacial Orthop, 2011,140(1):32-37.

标记点	编号	描述
Cdla L	1	左侧髁突最外侧点
Cdla R	2	右侧髁突最外侧点
Cds L	3	左侧髁突顶点
Cds R	4	右侧髁突顶点
Fmd L	5	左侧下颌第一磨牙颊侧远中边缘点
Fmd R	6	右侧下颌第一磨牙颊侧远中边缘点
Go L	7	左侧下颌角点
Go R	8	右侧下颌角点
Id	9	正中联合处牙槽骨最上点
Ml L	10	左侧下颌升支内下颌小舌点
Ml R	11	右侧下颌升支内下颌小舌点
Me	12	颏下点
Po	13	颏前点
QIE1 L	14	过左侧乙状切迹与下齿槽平面平行的
		平面,与左侧升支相交的最前点
QIE1 R	15	过右侧乙状切迹与下齿槽平面平行的
		平面,与右侧升支相交的最前点
QIE2 L	16	过左侧乙状切迹与下齿槽平面平行的
		平面,与左侧升支相交的最后点
QIE2 R	17	过右侧乙状切迹与下齿槽平面平行的
		平面,与右侧升支相交的最后点
Sigmoid notch L	18	左侧下颌升支乙状切迹点
Sigmoid notch R	19	右侧下颌升支乙状切迹点
33 ARB	20	33牙槽嵴顶颊侧中央边缘点
43 ARB	21	43牙槽嵴顶颊侧中央边缘点
34 ARB	22	34牙槽嵴顶颊侧中央边缘点
44 ARB	23	44牙槽嵴顶颊侧中央边缘点

测量值	标记点	描述
D1	5-6	Fmd L和Fmd R的线距
D2	14-16	QIE1 L和QIE2 L的线距
D3	15-17	QIE1 R和QIE2 R的线距
D4	1-2	Cdla L和Cdla R的线距
D5	9-12	Id和Me的线距
D6	5-10	Fmd L和Ml L的线距
D7	6-11	Fmd R和Ml R的线距
D8	4-8	Cds R和Go R的线距
D9	3-7	Cds L和Go L的线距
Angle 1	∠7-12-8	由双侧下颌角点和颏下点所成角
D10	7-13	Go L和Po的线距
D11	8-13	Go R和Po的线距
D12	7-8	Go L和Go R的线距
Angle 2	∠12-7-3	由Me、Go L和Cds L所成角
Angle 3	∠12-8-4	由Me、Go R和Cds R所成角
D13	20-22	下尖牙牙槽嵴顶颊侧缘宽度
D14	21-23	下第一双尖牙牙槽嵴顶颊侧缘宽度

测量项目		阻生组	对照组	P值	95%置信区间
矢状向	D2	41.21±3.14	40.85±3.32	0.470	-0.61~1.32
	D3	41.71±3.10	41.37±3.44	0.495	-0.64~1.31
	D6	35.58±3.92	37.56±4.14	0.000	-2.28~-0.46
	D7	36.17±3.91	38.11±4.34	0.000	-2.02~-0.17
	D10	80.82±4.64	83.54±4.97	0.000	-4.16~-1.30
	D11	80.98±4.46	83.53±5.10	0.000	-3.97~-1.14
垂直向	D5	30.79±2.96	31.28±3.11	0.283	-1.40~0.41
	D8	62.08±5.86	61.82±5.35	0.133	-1.76~0.69
	D9	61.45±6.08	60.63±5.47	0.134	1.10-4.54
横向	D1	45.95±4.09	47.15±2.84	0.000	0.23~1.73
	D4	121.04±7.57	120.68±6.77	0.734	-1.71~2.50
	D12	89.46±5.41	91.42±6.19	0.008	-3.19~-0.49
	D13	28.59±2.86	28.47±2.10	0.762	-0.63~0.86
	D14	41.21±2.52	40.88±2.14	0.350	-0.37~1.02
角度	Angle 1	73.25±4.61	70.40±4.61	0.000	1.48~4.22
	Angle 2	120.79±6.18	122.14±6.30	0.153	-3.20~0.51
	Angle 3	121.58±9.22	123.11±6.36	0.202	-3.89~0.83
