脉冲式掺铒钇铝石榴石激光与乙二胺四乙酸 联合治疗模式处理不同深度天然牙三壁骨缺损同期植入种植体的研究

doi:10.7518/hxkq.2021.06.015

华西口腔医学杂志 ›› 2021, Vol. 39 ›› Issue (6): 718-723.doi: 10.7518/hxkq.2021.06.015

脉冲式掺铒钇铝石榴石激光与乙二胺四乙酸联合治疗模式处理不同深度天然牙三壁骨缺损同期植入种植体的研究

把丽根·伯拉提汉null(), 林志辉, 满毅()

口腔疾病研究国家重点实验室国家口腔疾病临床医学研究中心四川大学华西口腔医院种植科，成都 610041

收稿日期:2020-12-01 修回日期:2021-09-10 出版日期:2021-12-01 发布日期:2021-12-03
通讯作者: 满毅 E-mail:baligen-bolatihan@163.com;manyi780203@126.com
作者简介:把丽根·伯拉提汉，住院医师，硕士，E-mail：baligen-bolatihan@163.com
基金资助:
国家重点研发计划(2016YFC1102705)

Effect of Er:YAG laser combined with ethylenediamine tetra acetic acid on three-walled periodontal intrabony defects adjacent to implant sites

Bolatihan Baligen(), Lin Zhihui, Man Yi()

State Key Laboratory of Oral Diseases & National Clinical Research Center for Oral Diseases & Dept. of Oral Implantology, West China Hospital of Stomatology, Sichuan University, Chengdu 610041, China

Received:2020-12-01 Revised:2021-09-10 Online:2021-12-01 Published:2021-12-03
Contact: Man Yi E-mail:baligen-bolatihan@163.com;manyi780203@126.com
Supported by:
National Key Research and Development Program of China(2016YFC1102705)

摘要/Abstract

摘要： 目的

评价种植同期联合应用脉冲式掺饵钇铝石榴石（Er:YAG）激光与乙二胺四乙酸（EDTA）处理天然牙三壁骨缺损的临床效果。

方法

选取单颗牙缺失伴天然牙近缺隙侧三壁骨缺损患者30例，按照垂直骨缺损深度分为组1和组2。两组均使用EDTA+Er:YAG激光联合应用处理天然牙暴露根面+同期种植+骨增量术，术后10 d行软组织愈合评估，记录并比较两组术后6月骨高度变化量以及修复后6月边缘骨吸收量，修复后6个月随访记录并比较天然牙的临床指标，包括邻牙探诊深度（PD）、牙周附着水平（CAL）、龈沟出血指数（SBI），比较两组天然牙保留率和种植体存留率。

结果

组1一期愈合率为92.31%，组2一期愈合率为82.35%，组1一期愈合率高于组2，但差异无统计学意义（P>0.05）。术后6月，组1和组2的骨高度量变化量分别为（2.85±1.81）、（4.92±2.22） mm，差异具统计学意义（P<0.05）；组1和组2边缘骨吸收量变化量为（0.70±0.32）、（1.25±0.47） mm，差异无统计学意义（P>0.05）。修复后6月，两组临床指标（PD、CAL、SBI）差异均无统计学意义（P>0.05）；两组天然牙保留率分别为100%、94.12%，种植体存留率均为100%。

结论

联合应用EDTA+Er:YAG激光处理不同深度天然牙三壁骨缺损同期种植病例均取得较好骨增量效果，且在组2骨增量效果优于组1。通过上述联合治疗以及同期植入种植体，将不同深度的三壁骨缺损均转化为有利于成骨的三维空间形态，恢复类似的牙周再附着效果，从而获得较好天然牙保留率、种植体存留率。

关键词: 种植, 激光, 骨下袋, 牙周再生, 骨增量, 骨缺损

Abstract: Objective

To investigate the clinical effect of Er:YAG laser combined with ethylenediamine tetra acetic acid (EDTA) on three-walled periodontal intrabony defects adjacent to implant sites.

Methods

A total of 30 patients with three-walled periodontal intrabony defects adjacent to implant sites were treated with the combination therapy. Patients with three-walled intrabony defects were divided into two groups according to the depth of the intrabony pocket between the implant and natural teeth. Evaluation of wound healing was performed 10 days after the operation, and bone augmentation was evaluated 6 months after the operation.

Results

Primary healing in group 1 was 92.31%, primary healing in group 2 was 82.35%. No significant difference was observed between the two groups (P>0.05). Bone augmentation in group 1 and group 2 were (2.85±1.81), (4.92±2.22) mm. There was significant difference between the two groups (P<0.05). New bone growth occurred more slowly in group 1 (0.70 mm±0.32 mm) than in group 2 (1.25 mm±0.47 mm) (P>0.05). Probe depths (PD), clinical attachment levels (CAL), and sulcus bleeding indices (SBI) showed no statistically significant difference between the two groups (P>0.05). The one-year survival rate of natural tooth in group 1 and group 2 were 100%, 94.2%, and the one-year survival rate of implants in both groups was 100%.

Conclusion

The effect of bone augmentation with combination therapy was more ideal in group 2 than in group 1. Implant placement with combination therapy may be a viable technique to reconstruct three-walled intrabony defects due to the space maintenance provided by implants and bone grafts and the good root surface biocompatibility provided by the Er:YAG laser and EDTA.

Key words: implantation, lasers, intrabony defect, periodontal regeneration, bone augmentation, bone defects

中图分类号:

R 783

把丽根·伯拉提汉null, 林志辉, 满毅. 脉冲式掺铒钇铝石榴石激光与乙二胺四乙酸联合治疗模式处理不同深度天然牙三壁骨缺损同期植入种植体的研究[J]. 华西口腔医学杂志, 2021, 39(6): 718-723.

Bolatihan Baligen, Lin Zhihui, Man Yi. Effect of Er:YAG laser combined with ethylenediamine tetra acetic acid on three-walled periodontal intrabony defects adjacent to implant sites[J]. West China Journal of Stomatology, 2021, 39(6): 718-723.

图/表 3

参考文献 16

1	Kreisler M, Kohnen W, Marinello C, et al. Bactericidal effect of the Er:YAG laser on dental implant surfaces: an in vitro study[J]. J Periodontol, 2002, 73(11): 1292-1298.
2	Deppe H. Laser in oral implantology[M]//Budihardja AS, Mücke T. Bone management in dental implantology, Switzerland: Springer, 2019: 169-192.
3	Roncati M, Gariffo A. Systematic review of the adjunctive use of diode and Nd:YAG lasers for nonsurgical pe-riodontal instrumentation[J]. Photomed Laser Surg, 2014, 32(4): 186-197.
4	Grover HS, Yadav A, Nanda P. A comparative evaluation of the efficacy of citric acid,ethylene diamine tetra acetic acid (EDTA) and tetracycline hydrochloride as root biomodification agents: an in vitro SEM study[J]. Int J Contemp Dent, 2011, 2(3): 1-7.
5	Man Y, Wu Q, Wang T, et al. Split pedicle roll envelope technique around implants and pontics: a prospective ca-se series study[J]. Int J Oral Maxillofac Surg, 2015, 44(10): 1295-1301.
6	Wachtel H, Schenk G, Böhm S, et al. Microsurgical access flap and enamel matrix derivative for the treatment of periodontal intrabony defects: a controlled clinical s-tudy[J]. J Clin Periodontol, 2003, 30(6): 496-504.
7	Aoki A, Mizutani K, Schwarz F. Periodontal and peri-implant wound healing following laser therapy[J]. Perio-dontol 2000, 2015, 68(1): 217-269.
8	Braun A, Jepsen S, Deimling D, et al. Subjective intensity of pain during supportive periodontal treatment using a sonic scaler or an Er:YAG laser[J]. J Clin Periodontol, 2010, 37(4): 340-345.
9	Alhabashneh R, Darawi O, Khader YS, et al. Gingival depigmentation using Er: YAG laser and scalpel technique: a six-month prospective clinical study[J]. Quintessence Int, 2018, 49(2): 113-122.
10	Abdul A, Arundeep KL, Farrukh F, et al. Effect of antimicrobial photodynamic therapy as an adjunct to nonsurgical treatment of deep periodontal pockets: a clinical study[J]. J Lasers Med Sci, 2016, 7(4): 220-226.
11	Miremadi SR, Cosyn J, Schaubroeck D, et al. Effects of root surface debridement using Er:YAG laser versus ultrasonic scaling-a SEM study[J]. Int J Dent Hyg, 2014, 12(4): 273-284.
12	Schwarz F, Jepsen S, Herten M, et al. Immunohistochemical characterization of periodontal wound healing following nonsurgical treatment with fluorescence controlled Er: YAG laser radiation in dogs[J]. Lasers Surg Med, 2007, 39(5): 428-440.
13	Sachdeva S, Agarwal V. Evaluation of commercially a-vailable biodegradable tetracycline fiber therapy in ch-ronic periodontitis[J]. J Indian Soc Periodontol, 2011, 15(2): 130-134.
14	Ruggeri A Jr, Prati C, Mazzoni A, et al. Effects of citric acid and EDTA conditioning on exposed root dentin: an immunohistochemical analysis of collagen and proteoglycans[J]. Arch Oral Biol, 2007, 52(1): 1-8.
15	Wong ME, Hollinger JO, Pinero GJ. Integrated proces-ses responsible for soft tissue healing[J]. Oral Surg Oral Med Oral Pathol Oral Radiol Endod, 1996, 82(5): 475-492.
16	Lippert BM, Teymoortash A, Folz BJ, et al. Wound hea-ling after laser treatment of oral and oropharyngeal cancer[J]. Lasers Med Sci, 2003, 18(1): 36-42.
