上颌侧切牙年轻恒牙牙中牙伴根尖周炎的牙髓血运重建治疗1例

doi:10.7518/hxkq.2022.06.014

华西口腔医学杂志 ›› 2022, Vol. 40 ›› Issue (6): 716-720.doi: 10.7518/hxkq.2022.06.014

上颌侧切牙年轻恒牙牙中牙伴根尖周炎的牙髓血运重建治疗1例

袁婧¹(), 余思静¹, 游梦², 张琼³, 叶玲¹, 高波¹()

^1.口腔疾病研究国家重点实验室国家口腔疾病临床医学研究中心四川大学华西口腔医院牙体牙髓病科，成都 610041
^2.口腔疾病研究国家重点实验室国家口腔疾病临床医学研究中心四川大学华西口腔医院放射科，成都 610041
^3.口腔疾病研究国家重点实验室国家口腔疾病临床医学研究中心四川大学华西口腔医院儿童口腔科，成都 610041

收稿日期:2022-01-09 修回日期:2022-03-21 出版日期:2022-12-01 发布日期:2022-11-23
通讯作者: 高波 E-mail:2283992105@qq.com;gaob@scu.edu.cn
作者简介:袁婧，住院医师，学士，E-mail：2283992105@qq.com
基金资助:
四川省科学技术厅重点研发项目(2020YFS0202)

Regenerative endodontic treatment of dens in dente in maxillary lateral incisor with immature root: a case report

Yuan Jing¹(), Yu Sijing¹, You Meng², Zhang Qiong³, Ye Ling¹, Gao Bo¹()

^1.State Key Laboratory of Oral Diseases & National Clinical Research Center for Oral Diseases & Dept. of Cariology and Endodontics, West China Hospital of Stomatology, Sichuan University, Chengdu 610041, China
^2.State Key Laboratory of Oral Diseases & National Clinical Research Center for Oral Diseases & Dept. of Radiology, West China Hospital of Stomatology, Sichuan University, Chengdu 610041, China
^3.State Key Laboratory of Oral Diseases & National Clinical Research Center for Oral Di-seases & Dept. of Pediatric Dentistry, West China Hospital of Stomatology, Sichuan University, Chengdu 610041, China

Received:2022-01-09 Revised:2022-03-21 Online:2022-12-01 Published:2022-11-23
Contact: Gao Bo E-mail:2283992105@qq.com;gaob@scu.edu.cn
Supported by:
Key Research and Development Program of Department of Science and Technology of Sichuan Province(2020YFS0202);Correspondence: Gao Bo, E-mail: gaob@scu.edu.cn

摘要/Abstract

摘要：

牙内陷是由牙发育时期成釉器过度卷叠或局部过度增殖，深入到牙乳头中而导致的牙齿形态异常，因其复杂的解剖结构，给常规的牙髓治疗带来困难和挑战。牙中牙的牙髓治疗为牙内陷最复杂的一种情况，本文报道1例上颌侧切牙年轻恒牙牙中牙伴根尖周炎的牙髓血运重建治疗的病例，结合锥形束CT的辅助诊断，对其治疗及预后进行评估。随访2年，牙根继续发育，根尖周炎症消失。本病例为年轻恒牙牙中牙的牙髓病及根尖周病提供了新的治疗策略。

关键词: 牙中牙, 牙髓血运重建, 锥形束CT

Abstract:

Dens invaginatus (DI) is a developmental anomaly as a result of a deepening or invagination of the enamel organ into the dental papilla during tooth development. In addition, DI is a malformation with varying anatomical features, which poses numerous challenges to treatment. Endodontic treatment of dens in dente is one of the most complica-ted cases of DI. Herein, an immature lateral incisor that employed regenerative endodontic treatment was presented. The mentioned tooth was diagnosed with DI, pulp necrosis, and chronic apical periodontitis. Hence, a favorable prognosis has been shown by a 2-year review with cone beam computed tomography. The tooth was functional with normal periodontal parameters and exhibited a normal response to the electric pulp sensibility test. Thus, regenerative endodontic treatment can also be recommended to endodontists for teeth with DI.

Key words: dens in dente, regenerative endodontic theatment, cone beam computed tomography

中图分类号:

R 781.05

袁婧, 余思静, 游梦, 张琼, 叶玲, 高波. 上颌侧切牙年轻恒牙牙中牙伴根尖周炎的牙髓血运重建治疗1例[J]. 华西口腔医学杂志, 2022, 40(6): 716-720.

Yuan Jing, Yu Sijing, You Meng, Zhang Qiong, Ye Ling, Gao Bo. Regenerative endodontic treatment of dens in dente in maxillary lateral incisor with immature root: a case report[J]. West China Journal of Stomatology, 2022, 40(6): 716-720.

图/表 5

图 1

图 2

图 3

表 1

图 4

参考文献 21

1	Hülsmann M. Dens invaginatus: aetiology, classification, prevalence, diagnosis, and treatment considerations[J]. Int Endod J, 1997, 30(2): 79-90.
2	Oehlers FA. Dens invaginatus (dilated composite odon-tome).Ⅰ. Variations of the invagination process and associated anterior crown forms[J]. Oral Surg Oral Med Oral Pathol, 1957, 10(11): 1204-1218.
3	Kim DS, Park HJ, Yeom JH, et al. Long-term follow-ups of revascularized immature necrotic teeth: three case reports[J]. Int J Oral Sci, 2012, 4(2): 109-113.
4	Lin LM, Ricucci D, Huang GT. Regeneration of the dentine-pulp complex with revitalization/revascularization therapy: challenges and hopes[J]. Int Endod J, 2014, 47(8): 713-724.
5	Yang J, Zhao YM, Qin M, et al. Pulp revascularization of immature dens invaginatus with periapical periodontitis[J]. J Endod, 2013, 39(2): 288-292.
6	马学娟, 陈旭. 牙内陷的诊断与治疗[J]. 中国实用口腔科杂志, 2016, 9(9): 519-522.
	Ma XJ, Chen X. Diagnosis and treatment of dens invaginatus[J]. Chin J Pract Stomatol, 2016, 9(9): 519-522.
7	Agrawal PK, Wankhade J, Warhadpande M. A rare case of type Ⅲ dens invaginatus in a mandibular second premolar and its nonsurgical endodontic management by u-sing cone-beam computed tomography: a case report[J]. J Endod, 2016, 42(4): 669-672.
8	Lin JC, Zeng Q, Wei X, et al. Regenerative endodontics versus apexification in immature permanent teeth with apical periodontitis: a prospective randomized controlled study[J]. J Endod, 2017, 43(11): 1821-1827.
9	顾雪凝, 权家苗, 李颂. 牙内陷的解剖形态和治疗方案选择[J]. 口腔疾病防治, 2019, 27(10): 662-666.
	Gu XN, Quan JM, Li S. Anatomical morphology and treatment options for dens invaginatus[J]. J Prevent Treat Stomatol Dis, 2019, 27(10): 662-666.
10	Silberman A, Cohenca N, Simon JH. Anatomical redesign for the treatment of dens invaginatus type Ⅲ with open apexes: a literature review and case presentation[J]. J Am Dent Assoc, 2006, 137(2): 180-185.
11	Narayana P, Hartwell GR, Wallace R, et al. Endodontic clinical management of a dens invaginatus case by using a unique treatment approach: a case report[J]. J Endod, 2012, 38(8): 1145-1148.
12	Mohammadi Z, Dummer PM. Properties and applications of calcium hydroxide in endodontics and dental traumatology[J]. Int Endod J, 2011, 44(8): 697-730.
13	Ruparel NB, Teixeira FB, Ferraz CC, et al. Direct effect of intracanal medicaments on survival of stem cells of the apical papilla[J]. J Endod, 2012, 38(10): 1372-1375.
14	Althumairy RI, Teixeira FB, Diogenes A. Effect of dentin conditioning with intracanal medicaments on survival of stem cells of apical papilla[J]. J Endod, 2014, 40(4): 521-525.
15	Jain G, Goel A, Rajkumar B, et al. Evaluation of effectiveness of intracanal medicaments on viability of stem cells of apical papilla[J]. J Pharm Bioallied Sci, 2020, 12(): S228-S232.
16	Kitikuson P, Srisuwan T. Attachment ability of human apical papilla cells to root dentin surfaces treated with either 3Mix or calcium hydroxide[J]. J Endod, 2016, 42(1): 89-94.
17	Montero-Miralles P, Martín-González J, Alonso-Ezpeleta O, et al. Effectiveness and clinical implications of the use of topical antibiotics in regenerative endodontic procedures: a review[J]. Int Endod J, 2018, 51(9): 981-988.
18	Schloss T, Sonntag D, Kohli MR, et al. A comparison of 2- and 3-dimensional healing assessment after endodontic surgery using cone-beam computed tomographic vo-lumes or periapical radiographs[J]. J Endod, 2017, 43(7): 1072-1079.
19	Bornstein MM, Lauber R, Sendi P, et al. Comparison of periapical radiography and limited cone-beam computed tomography in mandibular molars for analysis of anatomical landmarks before apical surgery[J]. J Endod, 2011, 37(2): 151-157.
20	李晓署, 梁燕, 谭旭, 等. 锥形束CT在上颌侧切牙牙中牙诊疗中的辅助应用1例[J]. 牙体牙髓牙周病学杂志, 2018, 28(7): 431-433.
	Li XS, Liang Y, Tan X, et al. The auxiliary application of CBCT in the diagnosis and treatment of dens in dente in maxillary lateral incisor: a case report[J]. Chin J Conserv Dent, 2018, 28(7): 431-433.
21	施雄, 李生娇, 周剑萍, 等. 锥形束CT在牙内陷诊断中的应用[J]. 口腔颌面外科杂志, 2019, 29(3): 164-168.
	Shi X, Li SJ, Zhou JP, et al. The role of CBCT in the diagnosis of dens invaginatus[J]. J Oral Maxillofac Surg, 2019, 29(3): 164-168.

距根尖孔距离/mm	牙根横截面面积
距根尖孔距离/mm	术前	术后2年	差值
1	4.698	5.321	0.623
2	7.264	9.961	2.697
3	9.100	12.088	2.988
4	10.773	13.975	3.202
5	12.533	14.729	2.196
